Barrel Shadeport Structures

Barrel Shadeport Structures
(2 Poles)

This is one of our new designs being a cantilevered Barrel style shadeport structure allowing easy parking access.

~~ Click for larger spec image ~~

Material

• Steel:
  Structural Steel tubing to specification depending on application
• Finish:
  All Steel coated with red oxide etch primer and finished with standard white or colour coded QD Enamel
• Foundations:
  Columns fixed into 600 x 600 x 800 of 25 MPA Concrete for standard applications.
• Netting:
  Depending on colour choice. All UV Deflection exceeds 95%
